Suzuki LTZ400 Series ATV (2003-2008) Service Repair Manual ^

<h3 class="f4">Suzuki LTZ400 Series ATV (2003-2008) Service Repair Manual</h3><div class="f5 gray lh-title ma0 mt2 mt1-m normal"><h3 class="f5">Description</h3><p>Clymer ATV repair manuals are written specifically for the do-it-yourself enthusiast. From basic maintenance to troubleshooting to complete overhaul, Clymer manuals provide the information you need. The most important tool in your tool box may be your Clymer manual, get one today.Every Clymer manual contains hundreds of original photographs and illustrations developed from a complete disassembly and assembly of a motorcycle. This, in addition to extensive research, allows Clymer to achieve an unmatched level of detail, accuracy and clarity.The step-by-step instructions and two-column text with large print are user-friendly. Bold figure numbers make it easy to quickly match instructions with illustrations and photos. Thumb-tabbed chapters, numbered table of contents and an extensive index make it possible to locate the desired section quickly.</p></div><div class="f5 gray lh-title ma0 mt2 mt1-m normal"><h3 class="f5">Contents</h3><p><strong>This Suzuki LT-Z400 Manual is 336 pages. QUICK REFERENCE DATA CHAPTER ONE / GENERAL INFORMATION</strong> Manual organization / Warnings, cautions and notes / Safety / Serial numbers / Fasteners / Shop supplies / Tools / Measuring tools / Electrical system fundamentals / Service methods / Storage / Specifications <strong>CHAPTER TWO / TROUBLESHOOTING</strong> Water damage / Starting the engine / Engine does not start / Poor idle speed performance / Poor, medium and high speed performance / Electrical testing / Starting system / Charging system / Ignition system / Lighting system / Fuel system / Engine overheating / Engine noises / Cylinder leakdown test / Clutch / Transmission / Suspension / Frame / Brakes <strong>CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP</strong> Maintenance schedule / Pre-Ride inspection / Air box drain plug / Air filter / Engine oil / Oil pressure check / Spark plug / Spark arrestor cleaning / Fuel line inspection / Fuel tank vent hose / Carburetor / Ignition timing / Valve clearance inspection / Compression check / Control cables / Cooling system / Tires and wheels / Battery / Drive chain and sprockets / Brake system / Shock absorbers / Front suspension / Swing arm bearing inspection / Rear suspension inspection / Skid plate inspection / Specifications <strong>CHAPTER FOUR / ENGINE TOP END</strong> Break-In period / Exhaust system / Cylinder head cover / Camshafts and cam chain tensioner / Cylinder head / Valves / Cylinder / Piston and piston rings / Specifications <strong>CHAPTER FIVE / ENGINE LOWER END</strong> Engine / Crankcase / Crankcase seals / Crankcase bearings / Engine balancer / Oil pump / Oil strainer / Oil pressure check valve / Oil tank / Crankshaft / Cam chain and rear guide / Balancer driven gear / Primary and balancer drive gears / Specifications <strong>CHAPTER SIX / CLUTCH AND EXTERNAL SHIFT MECHANISM</strong> Right crankcase cover / Clutch / Clutch release camshaft / Shift lever / Shift mechanism / Clutch cable replacement / Clutch lever replacement / Reverse shift cable replacement / Specifications <strong>CHAPTER SEVEN / TRANSMISSION AND INTERNAL SHIFT MECHANISM</strong> Transmission operation / Transmission service / Input shaft / Output shaft / Reverse gear and axle / Transmission inspection / Shift drum and forks / Specifications <strong>CHAPTER EIGHT / FUEL SYSTEM</strong> Carburetor / Throttle position sensor / Carburetor operation / Fuel valve / Throttle cable replacement / Choke cable replacement / Fuel tank / Specifications <strong>CHAPTER NINE / ELECTRICAL SYSTEM</strong> Electrical component replacement / Alternator cover / Lower idle gear / Stator assembly / Rotor and starter clutch / Starter / Starting system switches / Ignition system / Charging system / Radiator fan system / Coolant temperature warning circuit / Head...</p></div>

• Step-by-step procedures
• Easy-to-follow photos
• Complete troubleshooting section
• Valuable short cuts
